Atomos Sumo 19″ SE HDR Monitor Recorder and Switcher

Name: Atomos Sumo 19" SE HDR Monitor Recorder and Switcher
Brand: Atomos
SKU: 180842
Price: 89000 THB
Availability: OutOfStock

89,000 ฿

Out of Stock

Choose

Clear

SKU: N/A Category: Monitor & Photo Editing Equipment -จอมอนิเตอร์และอุปกรณ์แต่งภาพ Tags: Atomos, Monitor, Monitor 19" Brand: Atomos

จุดเด่นผลิตภัณฑ์

หน้าจอสัมผัสขนาด 1920 x 1080 QLED
อินพุต/เอาต์พุต HDMI 2.0 & 12G-SDI
Quad-HD Live Switching & การบันทึก 5-Ch
ความสว่าง 1200 cd/m² (±10%)
รองรับ ProRes RAW
8 บิต+FRC 422 ProRes / การเข้ารหัส DNxHR
โหมด HDR พร้อมไดนามิกเรนจ์ 10 สต็อป
อินพุต XLR สองช่องพร้อม +48V

สเปค Atomos Sumo 19″ SE HDR Monitor Recorder and Switcher

Display
Panel Type	Quantum Dot OLED
Display Size	48.3 cm / 19.00″
Resolution	1920 x 1080
Aspect Ratio	16:9
Touchscreen	Yes
Maximum Brightness	1200 cd/m²
Bit Depth / Color Support	8-Bit+FRC (1.07 Billion Colors)
HDR Compatibility	Hybrid Log Gamma
Pixels Per Inch (ppi)	120 ppi
Real-Time LUT Monitoring	SDR, HDR
Image Controls	Anamorphic De-Squeeze, False Color, Focus Peaking, OSD Flip, Pixel Zoom, RGB Parade, Vectorscope, Waveform, Zebra
Video I/O	1 x HDMI 2.0 Input 1 x HDMI 2.0 Output 4 x BNC (12G-SDI) Input 1 x BNC (12G-SDI) Output
Embedded Audio	HDMI: 8-Channel SDI: 12-Channel
Audio I/O	2 x XLR Input 2 x XLR Output 1 x 1/8″ / 3.5 mm Headphone Output
Built-In Speaker	2 x 5 W
Power I/O	2 x XLR 4-Pin (14.4 VDC) Input 1 x XLR 4-Pin (16.8 VDC) Input
Other I/O	1 x BNC (Genlock) Input 1 x 2.5 mm (LANC) Input
Media/Memory Card Slot	None
File System Support	exFAT
Format Support
Video Format	HDMI/SDI (10-Bit 4:2:2) UHD 4K: 60 DCI 4K: 60
Gamma Curve	DCI-P3, DCI-P3+, Panasonic V-Gamut, Rec709
Video Signal Conversion	HDMI to SDI SDI to HDMI
Timecode Support	Yes
Recording
Pulldown Conversion	2:2, 3:2
Camera Trigger	SDI, HDMI
Pre-Roll Record	Full HD: 8 Seconds 4K: 2 Seconds
Encoding Formats	x ProRes Raw ProRes 422 HQ 10-Bit DNxHR 422 HQ 10-Bit
Closed Caption Support	None
Reference Input	None
Phantom Power	+48 V
Power
DC Input Power	12 to 16.8 VDC
Built-In Battery	None
Battery Type	2 x V-Mount, Gold Mount
Power Consumption	75 W
Mounting
Mounting-Hole Pattern	100 x 100 mm
Mounting	10 x 1/4″-20 Female 5 x 3/8″-16 Female
Environmental
Operating Temperature	40°C / 72°F
General
Material of Construction	Aluminum, Polycarbonate
Dimensions	504 x 330 x 180 mm / 19.8 x 13 x 7.1″, Including Feet
Weight	5.45 / 12.02 lb kg
